MSHW-II
WINCOO
WINCOO offers the Automatic Girth Welder for tank fabrication applications. Unlike other girth welders on the market, WINCOO AGW comes standard with a Dual Drive System and other features unique to our machines. This self-propelled submerged arc welding system can reduce field storage tank welding time by 40% by increasing arc on time and reduce weld defects. The models run directly on the tank and carry the operator, eliminating the need for Scaffolding while ensuring operator comfort and safety. The girth welder, due to their modular design, are applicable for top down or bottom up constructed single or double wall storage tanks. our design allows us to offer custom-built units for special applications.
For the tank welding machine, we has been sold more than 20 countries in more than 1000 projects sites.We have confidence for the machine quality and after sale service. We can provide single side, double side crude oil, LNG tank, fuel tank, water tank horizontal seam, vertical seam and bottom plate/corner welding machine.In Middle East, we have sold to UAE, Saudi Arabia, Oman, Bahrain, Kuwait. In Africa, we have sold machine to Cameron, Sudan, Egypt, Senegal, Nigeria,Zambia,Ethiopia,Senegal,etc. We have sold to vietnam, Indonesia , Malysia,Philippines,Singapore, Mexco,Mogulia, Russia,etc.
Product | Model | Application |
Single sided girth welder | MSHW-I/Z | Storage tanks |
Double sided girth welder | MSHW-II | |
Jack-up Girth welder | MSHW-I/D | Jack Up tanks |
Light girth welder/ | MSHW-L | Tower |
Girth welder for LNG/LPG | MSHW-LNG | LNG&LPG Tanks |
Model | MSHW-I-Z/D |
Welding Currency | 80-800A |
Welding Voltage | 20-45V |
Welding Speed | 200-650mm/min |
Power Input | 380/3PH/50Hz |
Rated power | 25kw |
| Groove | V/K Groove |
Position | Horizontal seam(2G) |
Full traveling speed | 2650mm/min |
| Tank Dia | 5.0m and above |
Wire Dia | Φ2.0mm-Φ4.0mm |
Plate Thickness | 8-45mm |
Shell width | bottom-to-top 1.5-3.0m |
Torch adjustment | 3 axi |
Torch up/down adjustment | ±25mm |
Torch fwd/rev adjustment | ±25m |
Capacity of flux container | 60kg |
Wincoo Engineering Co., Ltd (WINCOO) is engaged in bringing the most suitable solutions/equipments for client, fabricators, EPC/C companies on pipe fabrication, tank construction, pipeline construction,industrial production lines, clean energy project and other industrial field.
We have ability of providing workable solutions to support clients to be awarded with shorter project execution time, fewer man-hour cost and higher efficiency construction/fabrication method and better quality during phase of project bidding.Based client's facility/site space availability, we are able to study/design and present matched configurations on project schedule, quality, cost and productivity to guarantee production pace is accordance with project requirement.To support project execution, we are always ready to work as fireman to give prompt supply on project materials from different consumables, tools, equipments/machines to special merchandise. With flexibility, we are also glad to perform as procurement agent in China to seek required supply resources.
