| Quantity: | |
|---|---|
WHM-24
WINCOO
NA | Name | Parameter |
1 | model | PHM-24 |
diameter | Φ60-630 | |
2 | Cutting mode | Flame or plasma |
3 | cutting thickness | plasma：3-20mm,flame: 5-45mm |
4 | Cutting length | 12000.0 mm |
5 | The workpiece ellipticity is required | ≤1% |
6 | Cutting speed | 10～2000mm/min |
7 | Move speed | 10～6000 mm/min |
8 | Cutting torch axial swing Angle | β=±45° |
9 | Cutting torch radial swing Angle | α=±45° |
10 | Ambient acceptable temperature | -20℃ -50℃ |
11 | Frequency | 50HZ /60HZ |
12 | Cutting accuracy is up to standard | ISO9013-2002&ISO8206-1991 |
13 | Chuck | Manual or electric (optional) 3 jaw linkage self-centering |
14 | Number of bracket | 3groups |
15 | Accuracy of cutting length | ±1.5mm |
17 | Maximum weight of pipe to be cut | 5000Kg |
The CNC plasma cutting machine for horizontal structure, mainly divided into: workpiece clamping mechanism, chuck rotary mechanism, pipeline support bracket, cutting torch walking mechanism, cutting torch rotary mechanism, copying tracking mechanism, plasma cutting system (flame cutting system), NUMERICAL control system, software system, etc. The cut steel pipe is hung on the pipe support device, which is equipped with two groups of rollers of different sizes to adapt to the change of steel pipe diameter. After the pipe is loaded, the steel pipe is clamped on the three-jaw self-centering chuck through the workpiece clamping mechanism.
User generated editor on cutting software for cutting data, and controlled by the CNC system institutions, according to the cutting data are accurate and efficient for cutting the workpiece clamping mechanism, in the process of pipe supports device for pipe fixed, support and drive, cutting torch travel mechanism and synthesis of curve workpiece rotation mechanism is responsible for the curve, Plasma cutting system (flame cutting system) is the cutting source, torch rotary mechanism is responsible for the bevel cutting task, copy tracking mechanism in coordination with other institutions to complete the torch heel height, levelness and ellipticity measurement, data compensation and other functions.
NAME | Detail configuration | Unit | QTY | REMARK |
PHM CNC plasma cutting machine | Mainframe of chuck drives | SET | 1 | Chuck clamps tube end, servo drive 360° unlimited rotation |
Movable cutting trolley | SET | 1 | Walk along the track axial direction to meet the cutting requirements of various positions | |
Industrial computer and servo control system chuck drive mainframe | SET | 1 | Fixed length pipe cutting, beveling, all kinds of straight/oblique intersecting line cutting opening, shrimp section cutting, etc | |
Heavy duty precision rigid base | SET | 1 | Using 200 rectangular tube welding after annealing stress relief treatment, 24KG finishing rail, not only to ensure high walking accuracy and meet the overall rigidity of the equipment, so the installation foundation requirements are low, after relatively leveling expansion bolts can be fixed | |
Cross type pipe support frame | SET | 3 | Meet the support of different pipe diameters | |
Cutting system | SET | 1 | Flame cutting system and plasma cutting |
1.Pipe diameter applicable: DN100-600 (φ114-630); DN150-800 (φ159-830); DN200-1200 (φ219-1219); DN400-1500 (φ406-1524)
2.Applicable wall thickness: ≤25mm (cutting up to plasma generator) ; ≤60mm (flame cutting)
3.Materials applicable: carbon steel, alloy steel, stainless steel and cryogenic steel
4.Cutting length: 6350MM or as per request
5.Bevel Shape: V type
6.Cutting direction: lengthwise
7.Roller bench:
1).Structure: three line roller with fixed distance
2).Roller bench Length:7000mm or 12000mm (or asper request)
3).Driving System: servo motor + precision reducer
4).Rev: 0-2.5M/Min (VF stepless speed adjustment)
5).Roller bench Material: 45#,Surface bluing treatment
6).Rotation Accuracy:<2.0MM
8.Number of axis under control: 2-6 Axis
1).Work piece axis of rotation(X)
2).Cutting the first work piece along the axis of axial movement(Y)
3).Cutting torch along the axial swing axis work piece (Z)
4).Cutting torch along the work piece swing radial axis (W)
5).Cutting the first spindle axis vertical take-off and landing (U)
6).Cutting nozzle strength out and draw back axis (V)
9.Trolley System:
1).Trolley stroke: 6350MM (moving lengthwise)
2).Cutting torch travel: 700MM (up/down); 300MM (left/right)
3).Cutting with: Plasma cutting (can be equip for flame cutting)
4).Cutting Torch Angle:±45°（adjustable）for plasma cutting; ±60°(adjustable) for flame cut
5).Cutting Torch Quantity: one pcs for plasma cutting torch, one pcs for flame cutting torch.
6).Angle error: <2°
7).Length fixing accuracy:<2.0MM
8).Control System: original import IPC or SH-2000H CNC Cutting System
9).Length-measuring system: CNC length measuring which is included in the control system.
10).Conveying system: built in a conveying system equipped with a lifter; one set of conveying system can be provided additionally for bevel cutting machine if necessary and conveying can be implemented manually or electrically.
11).Plasma Cutting power source: Hypertherm from USA(or as per customers’ demands)
